Tray 8 Dome Fiber Optic Splice Closure Featuring 8 Port Cable 8 to 16 Oval 74x54 and Maximum 9 Trays Capacity

Product Description:

The Dome Fiber Optic Splice Closure, model Gjs20-dr05A-7port, is an advanced and reliable solution designed for protecting fiber optic splices in a variety of outdoor environments. This product is specifically engineered to meet the demanding requirements of modern fiber optic networks, including FTTH fiber optic splice closure applications. Its robust design ensures that fiber optic cable connectors and splices are securely housed and protected from harsh environmental conditions, making it an essential component in the deployment of high-performance fiber optic communication systems.

One of the standout features of this Dome Fiber Optic Splice Closure is its impressive splice tray capacity. Each tray can accommodate between 12 to 24 cores, providing flexibility and scalability for network installations. The splice closure supports a maximum of 9 trays, enabling it to handle fiber core counts ranging from 12 to 288 cores. This capacity makes it ideal for large-scale fiber optic networks where high-density splicing is required, such as in FTTH (Fiber to the Home) deployments. The ability to manage up to 288 fiber cores within a single closure significantly reduces the need for multiple enclosures, simplifying network design and maintenance.

Designed with durability and quality in mind, the Dome Fiber Optic Splice Closure meets the IP68 rating standard. This ensures complete protection against dust ingress and prolonged immersion in water, guaranteeing that the internal fiber optic cable connectors and splices remain safe and functional even in the most challenging outdoor environments. The IP68 rating is a testament to the product’s capability to withstand extreme weather conditions, including rain, humidity, and temperature fluctuations, which are common in outdoor fiber optic installations.

The Dome Fiber Optic Splice Closure features a user-friendly design that facilitates easy installation and maintenance. Its dome-shaped enclosure provides ample space for organizing and securing fiber optic cable connectors and splice trays in an orderly manner. This design not only protects the splices but also allows technicians to perform splice management tasks efficiently, reducing downtime and operational costs. The 7-port configuration of the Gjs20-dr05A-7port model offers versatile cable entry and exit options, accommodating various network layouts and ensuring seamless integration with existing infrastructure.

In addition to its physical robustness, the Dome Fiber Optic Splice Closure is constructed from high-quality materials that resist corrosion and mechanical damage. This ensures long-term reliability and performance, which are critical for maintaining network integrity and minimizing service interruptions. The closure is compatible with a wide range of fiber optic cable types and connectors, making it a versatile choice for telecommunications providers and network integrators looking to deploy FTTH fiber optic splice closure solutions.

Overall, the Dome Fiber Optic Splice Closure is an indispensable component for any fiber optic network requiring secure, high-capacity, and environmentally protected splice management. Whether used in urban or rural FTTH installations, its high splice tray capacity, IP68 quality rating, and flexible port configuration make it a superior choice for safeguarding fiber optic cable connectors and ensuring optimal network performance. Investing in this closure means investing in the reliability and longevity of your fiber optic infrastructure.

Features:

• Product Name: Dome Fiber Optic Splice Closure
• Maximum Trays: Supports up to 9 trays for fiber management
• Cable Ports: 8 ports suitable for 8 to 16 cables, including 1 oval port sized 74x54 mm
• Fiber Core Capacity: Accommodates 12 to 288 fiber cores
• Splice Tray Capacity: Each tray supports 12 to 24 fiber cores
• Quality Rating: IP68 rated for superior protection against dust and water
• Compatible with Fiber Optic Cable Connectors for reliable connections
• Ideal for use as an ftth fiber optic splice closure in fiber-to-the-home applications
• Functions effectively as a Fiber Optic Joint Closure, ensuring secure fiber splicing and protection

Technical Parameters:

Applications:

The Dome Fiber Optic Splice Closure, model GJS20-DR05A-7PORT, is an essential component designed to provide robust and reliable protection for fiber optic cable connectors in various environments. Its IP68 protection level ensures that the enclosure is completely dust-tight and can withstand continuous immersion in water, making it ideal for both outdoor and indoor use. This high protection standard guarantees the safety and integrity of the fiber optic cable connectors housed within, even under harsh environmental conditions.

This product is widely used in telecommunications networks, data centers, and other critical infrastructures where maintaining the performance and connectivity of fiber optic cables is paramount. The Dome Fiber Optic Splice Closure is perfect for applications involving the splicing and protection of fiber optic cable connectors, allowing for efficient management of fiber optic connections while safeguarding against moisture, dust, and mechanical damage.

Outdoor installation scenarios often include underground ducts, aerial poles, and direct burial applications where durability and environmental resistance are crucial. The IP68-rated dome closure ensures that fiber optic cable connectors remain secure from external elements such as rain, dust, and temperature fluctuations. Additionally, its versatility allows for seamless integration into indoor environments like equipment rooms and communication hubs, where controlled protection and easy access to fiber optic cable connectors are necessary.

Furthermore, the Dome Fiber Optic Splice Closure is designed to support up to 7 ports, making it suitable for complex network configurations requiring multiple fiber optic cable connectors to be spliced and managed within a single enclosure. This makes it an excellent choice for expanding network infrastructure or upgrading existing fiber optic systems.

For companies and service providers seeking to evaluate the product before committing to large orders, a free sample of the Dome Fiber Optic Splice Closure is available. This allows for hands-on testing and confirmation that the product meets specific project requirements.

In summary, the Dome Fiber Optic Splice Closure offers a high level of protection, flexibility, and reliability for fiber optic cable connectors, making it an indispensable solution for both outdoor and indoor fiber optic cable management applications.
